Slim 1000Ma DALI Dimmable Led Driver , 30W Constant Current Led Power Supply 28 VDC
Short Features :
> Type : DALI Dimmable led driver / Constant Current Led Driver
> input voltage range : 100~240VAC
> output : 18~30VDC 1050mA 30W
> Effiency : 85% minimum
> PF : >0.95
> Ripple and Noise : 100mV maximum
> IP rate : IP64
> Output type : constant current
> Dimming method : DALI / PWM / 0~10V dimming method
> Dimension : 183(H)*50(W)*32(H)mm
> Certificate : UL,CE,FCC,GS, SAA,C-TICK,CB,KC certificates.
> Safety protection : over load, over voltage, short ciruict, open load protection.
Specifications
|
Input Rated Voltage :
|
100Vac~240Vac
|
|
Input Frequency Range:
|
47Hz~63Hz
|
|
Input Inrush Current :
|
1.8A max
|
|
Efficiency :
|
85%(MIN)at Rated Voltage
|
|
Output:
|
18~30VDC 1050mA
|
|
Output power :
|
30W
|
|
Ripple and Noise :
|
<150Mv at full road with 20MHz bandwidth
|
|
Turn On Delay Time:
|
<3S (AC:110V and full load)
|
|
Safety protection :
|
over voltage and current protection.
|
|
Leakage Current:
|
<5mA
|
|
Output typer:
|
Constant current
|
|
Isolation rate:
|
isolation
|
|
Diming function:
|
DALI/PWM dimming funciton
|
|
Certificate:
|
CE GS TUV UL/CUL FCC ROHS,SAA,PSE,C-TICK
|
|
Safety Standard :
|
EN 55015:2006; EN 61547:1995+A1:2000 ;EN 61000-3-2:2006; EN61000-3-2:1995+A2:2005; EN 61347-1:2008 EN 61347-2-13:2006
|
|
Application:
|
For led light, led strip, led down light, led tube etc….
|
Applications :
For led light, led strip, led down light,led tube etc….
INSTRUCTION :
-For indoor application, can meet IP65 waterproof rate.
-The mains plug is used as the disconnect device, the disconnect device shall be readily operable.
-The socket-outlet shall be installed near the equipment and shall be easily accessible.
-No naked flame source, such as lighted candles, should be placed on the apparatus.
-Maximum operating ambient for the equipment is 40℃.
-The apparatus should not be used in a confined space such as a bookcase.
-This appliance is not intended for use by persons (including children) with reduced physical,
sensory, or mental capacities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their Safety.
-Children should be supervised to ensure that they do not play with the appliance.
