200W 5V 40A LED Color words, Shinning Words, LED Display Power Supply
SPECIFICATION |
||||||||||
MODEL |
ESH- 200W-3.3 |
ESH- 200W-5 |
ESH- 200W-7.5 |
ESH- 200W-12 |
ESH- 200W-15 |
ESH- 200W-24 |
ESH- 200W-36 |
ESH- 200W-48 |
||
OUTPUT |
DC VOLTAGE |
3.3V |
5V |
7.5V |
9V |
12V |
15V |
24V |
48V |
|
RATED CURRENT |
40A |
40A |
27A |
17A |
14A |
8.8A |
5.9A |
4.4A |
||
CURRENT RANGE |
0 ~ 40A |
0 ~ 40A |
0 ~ 27A |
0 ~ 17A |
0 ~ 14A |
0 ~ 8.8A |
0 ~5.9A |
0 ~ 4.4A |
||
RATED POWER |
132W |
200W |
202.5W |
204 W |
210W |
211.2W |
210.6W |
211.2W |
||
RIPPLE & NOISE (max.) Note.2 |
150mVp-p |
150mVp-p |
150mVp-p |
150mVp-p |
150mVp-p |
150mVp-p |
240mVp-p |
240mVp-p |
||
VOLTAGE ADJ. RANGE |
2.97 ~ 3.7V |
4.5 ~ 5.6V |
6 ~ 9V |
10 ~ 13.5V |
13.5 ~ 18V |
20 ~ 26.4V |
32 ~ 40V |
41 ~ 56V |
||
VOLTAGE TOLERANCE Note.3 |
+/-2% |
|
+/-1% |
+/-1% |
+/-1% |
+/-1% |
+/-1% |
+/-1% |
||
LINE REGULATION |
+/-0.5% |
+/-0.5% |
+/-0.5% |
+/-0.5% |
+/-0.5% |
+/-0.5% |
+/-0.5% |
+/-0.5% |
||
LOAD REGULATION |
+/-2% |
+/-1% |
+/-0.5% |
+/-0.5% |
+/-0.5% |
+/-0.5% |
+/-0.5% |
+/-0.5% |
||
SETUP, RISE TIME |
1000ms, 16ms/230VAC 1000ms, 50ms/115VAC at full load |
|||||||||
HOLD UP TIME |
20ms/230VAC 16ms/115VAC at full load |
|||||||||
INPUT |
VOLTAGE RANGE |
85 ~ 132VAC / 176 ~ 264VAC selected by switch 248 ~ 373VDC |
||||||||
FREQUENCY RANGE |
47-63Hz |
|||||||||
EFFICIENCY (Typ.) |
75% 200% |
79% |
82% |
85% |
85%
|
87% 200% 200% |
88%
|
89% |
||
AC CURRENT |
4.5A/115VAC 2.5A/230VAC |
|||||||||
INRUSH CURRENT (max.) |
COLD START 45A |
|||||||||
LEAKAGE CURRENT |
<3.5mA / 240VAC |
|||||||||
PROTECTION |
OVER LOAD |
105-150%rated output power |
||||||||
Protection type : Constant current limiting, recovers automatically after fault condition is removed |
||||||||||
OVER VOLTAGE |
3.8 ~ 4.9V |
5.75 ~ 6.75V |
9.4 ~ 10.9V |
13.8 ~ 16.2V |
18 ~ 21V |
27.6 ~ 32.4V |
41.4 ~ 46.8V |
57.6 ~ 67.2V |
||
Protection type :Shut down O/P voltage, re-power on to recover |
||||||||||
OVER TEMPERATURE |
U1 Tj 140 typically (U1) detect on main control IC |
|||||||||
Protection type : Shut down O/P voltage, recovers automatically after temperature goes down |
||||||||||
ENVIRONMENT |
WORKING TEMP. |
-20 ~ +50 (Refer to output load derating curve) |
||||||||
WORKING HUMIDITY |
20-90% RH |
|||||||||
STORAGETEMP., MIDITY |
-20-+85℃, 10-95% RH |
|||||||||
TEMP. COEFFICIENT |
+/-0.03%/(0-50℃) |
|||||||||
VIBRATION |
10-50HZ |
|||||||||
SAFETY &EMC |
SAFETY STANDARDS |
UL60950-1approved |
||||||||
WITHSTAND VOLTAGE |
I/P-O/P:3KV I/P-FG:1.5KV O/P-FG:0.5KV AC |
|||||||||
ISOLATION RESISTANCE |
I/P-OP, IP/FG, OP/FG:100M OHMS/500VDC/25C/70%RH |
|||||||||
EMICONDUCTION& DIATION |
Design refer to EN55022 (CISPR22) Class A |
|||||||||
EMS IMMUNITY |
Design refer to EN61000-4-2, 3, 4, 5, 6, 8, 11, ENV50204, EN55024, light industry level, criteria A. |
|||||||||
OTHERS |
MTBF |
271.9K hrs min. MIL-HDBK-217F(25℃) |
||||||||
DIMENSION |
215*115*50mm (L*W*H) |
|||||||||
PACKING |
0.93Kg; 12pcs/12Kg/0.92 CUFT |
|||||||||
NOTE |
1:All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature. |
|||||||||
2:Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. |
||||||||||
3:Tolerance : includes set up tolerance, line regulation and load regulation. |
||||||||||
4:Line regulation is measured from low line to high line at rated load. |
||||||||||
5:Load regulation is measured from 0% to 100% rated load. |
||||||||||
6:The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies. |
