Indoor Full Color LED Display of 6 mm Pixel with 3528 LED 192 × 192 Module

Product Details:

Place of Origin:	China
Brand Name:	Dreamway
Certification:	CE,ROHS
Model Number:	P6

Payment & Shipping Terms:

Minimum Order Quantity:	negotiable
Price:	negotiable
Packaging Details:	Plywood case
Delivery Time:	20 days after receiving the deposit
Payment Terms:	T/T, Western Union
Supply Ability:	2000sq.m/Month

Contact Now

Detailed Product Description

Type:	PH6	LED Module:	32 × 32 Dots
Module Size:	192 × 192 Mm	LED Type:	SMD3528
Cabinet Size:	960 × 768 Mm	Thickness:	9.5 Cm
Weight:	22 Kg/pc	Controller:	LINSN

Full Color Led Outdoor Advertising Screens 6 mm Pixel 192 × 192 Module

Quick Detail:

1. 192 × 192 mm LED module;
2. 960 × 768 mm cabinet size;
3. 5 × 4 pcs modules per cabinet;
4. 160 × 128 pixels for each cabinet;
5. LINSN controller;
6. 2 years warranty.

Detail Description:

Each cabinet is 960 by 768 mm, composed with 5 by 4 pcs LED modules, 1/16 scan, 1400 nits;
It is controlled with LINSN controller, easy operation, high refresh rate;
We provide 2 years warranty as what we promise.

Application:

Indoor full color LED display is for indoor advertising like shop, hotel, meeting room, etc.

Specifications:

Pixel Pitch	6 mm
LED Composition	1R1G1B
LED Type	SMD3528
Module Pixel	W 32 × H 32 dots
Module Size	W 192 × H 192 mm
Cabinet Dimension	W 960 × H 768 × T 95 mm
Screen Size	W 5.76 × H 3.072 m
Screen Resolution	W 960 × H 512 = 491,520
Color	Black
Drive Method	1/16 scan constant current
Luminance	More than 1,400 nits/sq.m
Weight	about 22 kg/pc
LED Chip	EPISTAR
Drive IC	JXI5020
Control Method	Synchronous control with PC
Controller	LINSN
Power Supply	220V 60HZ
Brand	Chuanglian
Package	Plywood case
Warranty	2 years

Indoor Full Color LED Display of 6 mm Pixel with 3528 LED 192 × 192 Module 0

6 mm Indoor Advertising LED Display, Indoor LED Display Screen, P6 Indoor LED Display Board
